Technical specs

Venue acoustics designed in collaboration with Acoustic researcher & inventor, PhD Niels W. Adelman-Larsen and his company Flex Acoustics, and rated “on par with best concert halls (rock/pop) in Denmark”.

Creating the great sound we chose to collaborate with Bose Scandinavia and are the first venue in Scandinavia to use the Bose Professional ShowMatch array loudspeakers – the newest DeltaQ technology design – which feature replaceable waveguides that allow changing coverage and asymmetrical patterns, optimized for Karosserifabrikken for top-class sound quality.

Stage

  • Height 75 cm
  • Width at back wall 650 cm – width at front 750 cm.
  • Depth 420 cm
  • Wing, stage left 160 cm x 200 cm
  • Speakers flown from truss 2 – approx 600 cm apart, lowest point 150 cm
  • Direct access between Stage and Backstage
  • Get in via double door only 10 feet from stage – direct to parking, level floor
  • Stage w/black carpet
  • 1×16 amp, 2×10 amp on stage back wall
  • 1×32 amp on stage cable box
  • Backdrop can be attached to underside of truss 1, 280 cm height

FOH (stationary)

  • Located approx 12 meters from stage, off center
  • On enclosed podium, 2×2.2 meters, 40 cm height
  • Central control of ceiling lights + Fire equipment
  • Digital cabling direct to stage
  • Light desk set up on podium under ceiling
  • On request, FOH can be set up closer to stage in crowd.

Lights & haze

  • ChamSys MagicQ MQ50 console
  • Chauvet Hurricane Haze4D controlled from light desk
  • Chauvet 9 x moving head (truss 1: 5 spot + 4 wash)
  • Chauvet 4 x moving head (truss 2: 4 spot)
  • 4 x ROBE AT250 color spot (stage floor)
  • 2 x Eve lamps covering front of stage(truss 3)
  • 5 x 3000k Fresnel theater spots w/barn doors (truss 3)
  • 4 x Core fresnel (truss 2)
  • 3 x Core fresnel wallmounted on each side of stage
  • 4 x blinders (truss 2+3)
  • 4 x Power Strobe 1500

Sound

  • Bose DeltaQ ShowMatch. 2×4 top, 4×18 inch bass
  • 2 x Bose RMU 208 front fill (controlled separately from main PA)
  • Powersoft X8 amplifier
  • Powersoft T302 amplifier driving front fill
  • Midas M32 Live sounddesk connected to 32 channel stagebox
  • 5 Turbosound TFM122M-AN monitors
  • 3 Turbosound TFM152M-AN monitors
  • Shure microphone package / stands for drum kit as well as number of Shure 57 & 58

Alutruss (30×30)

  • (1) Mounted directly on back wall, 7 meters wide
  • (2) Mounted directly over stage front, 12 meters wide
  • (3) Mounted 3 meters in front of stage, 8meters wide
  • All truss are fixed and can not be lowered
  • Lower edge 290 cm over stage level
